?A2CP12024射頻放大器Teledyne防務電子

發布時間：2024-12-31 17:15:52 瀏覽：623

A2CP12024射頻放大器是款基于Teledyne防務電子制造性能卓越放大器，具備高至24 dB的增益值，低噪聲系數為3.2dB，頻率范圍從6 GHz到12 GHz，采用標準Tray封裝。A2CP12024主要用于通信系統、機載雷達和電子戰系統等需要高精度增益控制和迅速響應的應用。

特征

頻率范圍: 6 GHzto12 GHz

工作電壓: 8 V

工作電流: 84 mA

增益值: 24 dB

NF—噪聲系數: 3.2 dB

P1dB - 壓縮點: 13.5 dBm

OIP3 - 三階截點: 20 dBm

最低溫度: - 55 C

最高溫度: + 85 C

封裝: Tray

深圳市立維創展科技是Teledyne防務電子的經銷商，提供Teledyne防務電子產品涵蓋LDMOS、GaN、GaAs和InP。Teledyne防務電子產品支持寬頻帶、窄帶、脈沖放大器，頻率1MHz~220GHz，功率mW~10kW，優勢渠道提供Teledyne防務電子訂貨，歡迎咨詢。

Frequency (Min.)	5.0-12.0 GHz	6.0-12.0 GHz	6.0-12.0 GHz
Small Signal Gain (Min.)	24.0 dB	23.0 dB	22.5 dB
Gain Flatness (Max.)	±1.2 dB	±1.5 dB	±1.7 dB
Noise Figure (Max.)	3.2 dB	3.7 dB	4.2 dB
SWR (Max.) Input/Output	1.8:1	2.0:1	2.0:1
Power Output (Min.) @ 1dB comp.	+13.5 dBm	+12.5 dBm	+12.5 dBm
Reverse Isolation	35 dB	—	—
DC Current (Max.)	84 mA	94 mA	100 mA
