?F1068插入式射頻隔離器WENTEQ

發布時間：2024-10-23 17:03:33     瀏覽：545

WENTEQ提供全方位窄帶寬和寬帶射頻和微波隔離器及其同軸、插入式和波導配備的循環器產品。F1068插入式射頻隔離器包含800~2700MHz，30-400MHz的頻率范圍。

主要特征：

頻率范圍：800~2700MHz，30-400MHz頻帶寬度

插入式配置

體型小，成本費用低

功率處理+30瓦，

操作溫度-30~+60°C

客戶指定調制頻率和頻帶寬度

深圳市立維創展科技是WENTEQ的經銷商，主要提供WENTEQ產品包括環形器、隔離器、負載終端等，產品原裝進口，質量保證，價格優勢，歡迎咨詢。


Part No.

Freq Range MHz

Insertion Loss, dB

Reverse Isolation, dB

VSWR

Forward Power, Watts

Reverse Power Watts

Temp. Range, °C

F1068-0089-15

860-960

0.6 Max

≥ 18

≤ 1.3

≥ 30

≥ 10

-30 ~ +60

F1068-0091-03

900~930

0.5 Max

≥ 22

≤ 1.2

≥ 30

≥ 10

-30 ~ +60

F1068-0136-20

1220-1500

0.5 Max

≥ 20

≤ 1.2

≥ 30

≥ 10

-30 ~ +60

F1068-0190-02

1885-1915

0.4 Max

≥ 23

≤ 1.2

≥ 30

≥ 10

-30 ~ +60

F1068-0180-06

1750-1850

0.5 Max

≥ 20

≤ 1.2

≥ 30

≥ 10

-30 ~ +60

F1068-0235-13

2200-2500

0.5 Max

≥ 20

≤ 1.2

≥ 30

≥ 10

-30 ~ +60

F1068-0255-12

2400-2700

0.5 Max

≥ 20

≤ 1.2

≥ 30

≥ 10

-30 ~ +60
