ISW-18 WR137波導隔離器MCLI

發布時間：2024-09-13 08:44:00     瀏覽：6135

ISW-18 WR137波導隔離器MCLI

　　產品規格

　　- 頻率范圍: 5.900至7.125 GHz

　　- 隔離度: 28 dB(典型值)，25 dB(規格范圍內)

　　- 插入損耗: 最大0.20 dB

　　- 電壓駐波比: 1.08:1(典型值)，1.13:1(規格范圍內)

　　- 工作溫度范圍: -30℃至+70℃

　　- 功率容量: 反向5W，正向25W

　　- 參考法蘭: CMR137:UER70

　　請注意，隔離度和電壓駐波比在不同條件下可能有所不同，具體數值請參考產品技術文檔或與制造商確認。深圳市立維創展科技有限公司，授權代理銷售MCLI產品，歡迎客戶咨詢。
