?100W寬輸出電壓電源模塊XP power

發布時間：2024-02-21 17:12:20 瀏覽：6268

XP power的100W寬輸出電壓電源模塊具備緊湊的 100W DC-DC 轉換器解決方案，選用標準規范?磚式封裝形式，并具有用作傳導冷卻的集成化基板。

100W寬輸出電壓電源模塊具備 2:1 輸入范圍（包含 18 至 36VDC 和 36 至 75VDC）及其 4:1 輸入范圍（包含 9 至 36VDC 和 18 至 75VDC）。

100W寬輸出電壓電源模塊標準技術包括：±10% 輸出電壓調節、遠程檢測、遠程開/關、寬溫度范圍，并包含過電流、過溫度和過電壓保護。

深圳市立維創展科技有限公司授權代理銷售XP POWER電源模塊產品。產品包括：AC-DC電源、DC-DC轉換器、高壓AC-DC電源、高壓DC-DC轉換器、射頻電源系統、三相電源。歡迎咨詢。

XP power.png

型號名稱	功率	輸入電壓	輸出電壓	輸出電流
MTH100	100W	10 至 40 VDC	100V	10A
QSB10024S3V3	100W	9 至 36 VDC	3.3V	30A
QSB10024S05	100W	9 至 36 VDC	5V	20A
QSB10024S12	100W	9 至 36 VDC	12V	8.3A
QSB10024S15	100W	9 至 36 VDC	15V	6.7A
QSB10024S24	100W	9 至 36 VDC	24V	4.17A
QSB10048S05	100W	18 至 75 VDC	5V	20A
QSB10048S12	100W	18 至 75 VDC	12V	8.3A
QSB10048S15	100W	18 至 75 VDC	15V	6.7A
QSB10048S24	100W	18 至 75 VDC	24V	4.17A
QSB10048S3V3	100W	18 至 75 VDC	3.3V	30A
ICH10024S05	100W	18 至 36 VDC	5V	20A
ICH10024S12	100W	18 至 36 VDC	12V	8.3A
ICH10024S15	100W	18 至 36 VDC	15V	6.7A
ICH10024S24	100W	18 至 36 VDC	24V	4.17A
ICH10024S3V3	100W	18 至 36 VDC	3.3V	20A
ICH10024WS05	100W	9 至 36 VDC	5V	20A
ICH10024WS12	100W	9 至 36 VDC	12V	8.3A
ICH10024WS15	100W	9 至 36 VDC	15V	6.7A
ICH10024WS24	100W	9 至 36 VDC	24V	4.17A
ICH10024WS3V3	100W	9 至 36 VDC	3.3V	20A
ICH10048S05	100W	36 至 75 VDC	5V	20A
ICH10048S12	100W	36 至 75 VDC	12V	8.3A
ICH10048S15	100W	36 至 75 VDC	15V	6.7A
ICH10048S24	100W	36 至 75 VDC	24V	4.17A
ICH10048S3V3	100W	36 至 75 VDC	3.3V	20A
ICH10048WS05	100W	18 至 75 VDC	5V	20A
ICH10048WS12	100W	18 至 75 VDC	12V	8.3A
ICH10048WS15	100W	18 至 75 VDC	15V	6.7A
ICH10048WS24	100W	18 至 75 VDC	24V	4.17A
ICH10048WS3V3	100W	18 至 75 VDC	3.3V	20A
